FLEXIBLE CLAMP SENSOR KEW 8135
฿24,500.00
สินค้าหมดแล้ว
[wcboost_compare_button]
Product Overview
| Applicable model | 5010, 5020, 6305(*), 6315(*) |
|---|
Specification
| Conductor size | φ75 mm (max) |
|---|---|
| Rated current | AC 50A |
| Output voltage | AC 500mV/ AC 50A (10mV/A ) |
| Accuracy | ±1.0%rdg±0.5mV (45 to 65Hz) (0 to 50A) ±1.5%rdg±0.5mV (40 to 300Hz) (0 to 20A) ±1.5%rdg±0.5mV (300Hz to 1kHz) (0 to 5A) |
| Phase shift | within ±3.0° (45 to 65Hz) within ±4.0° (40Hz to 1kHz) |
| Cable length | Approx. 3m |
| Output connector | MINI DIN 6PIN |
| Output impedance | 100Ω or less |
| Applicable standards | IEC 61010-1 , IEC 61010-2-032 CAT IV 300V / CAT III 600V Pollution degree 2 , IEC 61326 |
| Operating temperature and humidity range | -10 to 50°C , Relative humidity 85% or less (no condensation) |
| Dimension | 65（Ｌ）×24（Ｗ）×22（Ｄ）mm |
| Weight | Approx. 170 g |
| Accessories | 9095 (Carrying case) Instruction manual , Cable marker |
ข้อมูลเพิ่มเติม
| น้ำหนัก | 0.2 กก. |
|---|---|
| ขนาด | 7 × 3 × 3 เซนติเมตร |
