FLEXIBLE CLAMP SENSOR KEW 8130 AC 1000A
฿18,000.00
มีสินค้าอยู่ 6
[wcboost_compare_button]
Product Overview
| Applicable model | 5010(*), 5020(*), 5050(*), 6300, 6305, 6310, 6315 |
|---|
Specification
| Conductor size | max.Ø110mm |
|---|---|
| Rated current | AC 1000A |
| Output voltage | AC 500mV / 1000A (AC 0.5mV/A) |
| Accuracy | ±0.8%rdg±0.2mV (45Hz to 65Hz) ±1.5%rdg±0.4mV (40Hz to 1kHz) |
| Phase shift | within ±2.0° (45Hz to 65Hz) |
| Cable length | Approx. 3m |
| Output connector | MINI DIN 6PIN |
| Output impedance | 100Ω or less |
| Applicable standards | IEC 61010-1 , IEC 61010-2-030 IEC 61010-2-032 CAT IV 300V / CAT III 600V Pollution degree 2 IEC 61326 |
| Operating temperature and humidity range | -10 to 50°C , relative humidity 85% or less (no condensation) |
| Weight | Approx. 180g |
| Accessories | 9095 (Carrying case) Instruction manual , Cable marker |
ข้อมูลเพิ่มเติม
| น้ำหนัก | 0.3 กก. |
|---|---|
| ขนาด | 20 × 25 × 5 เซนติเมตร |
| Conductor size | max.Ø110mm |
| Rated current | AC 1000A |
| Output voltage | AC 500mV / 1000A (AC 0.5mV/A) |
| Accuracy | ±0.8%rdg±0.2mV (45Hz to 65Hz) ±1.5%rdg±0.4mV (40Hz to 1kHz) |
| Phase shift | within ±2.0° (45Hz to 65Hz) |
| Cable length | Approx. 3m |
| Output connector | MINI DIN 6PIN |
| Output impedance | 100Ω or less |
| Applicable standards | IEC 61010-1, IEC 61010-2-030 IEC 61010-2-032 CAT IV 300V / CAT III 600V Pollution degree 2 IEC 61326 |
| Operating temperature and humidity range | -10 to 50°C, relative humidity 85% or less (no condensation) |
| Weight | Approx. 180g |
| Accessories | 9095 (Carrying case) Instruction manual, Cable marker |
IM_8130_92-2177_A_en_92-2858_0_th_P-1.pdf
