เฟล็กซ์ซิเบิ้ลแคล้มป์เซนเซอร์ RC-100, 100A, Dia. 16mm
RC series
Ø6 Flexible Rogowski coil fixed by cable ties.
- High linearity from 1A to 100A
- Wide dynamic range
- Very useful with large size or awkward shaped conductors or in places with limited access
- No danger from open-circuited secondary
- Not damaged by large overloads
- Non-intrusive, no power drawn from the main
- Measurement uniformity at any position of the conductor inside the coil
- Excellent degree of rejection to the external current conductor
฿2,600.00
มีสินค้าอยู่ 3
[wcboost_compare_button]
MODEL RC-100
| Window size | 16 mm |
| Reference Rated current | 100A |
| Weight | Approx 80-100g | |
| Coil Resistance | from 100 to 300 | |
| Maximum current measurable | 100A | |
| Coil | 6 mm | |
| Lead lengt | 2 m. | |
| Output (di/dt) | Uncalibrated | 60mV/kA@50Hz 72mV/kA@60Hz |
| Calibrated | 50mV/kA@50Hz 60mV/kA@60Hz | |
| Read Accurac | Calibrated < 5% tolerance (central position, 25°C) Uncalibrated < 5% tolerance (central position,25 °C) | |
| Temperature | Uncalibrated 200ppm/°C | |
| Calibrated 400ppm/°C | ||
| Position Erro | ±1% max | |
| Output on 0A (zero drift) | ≤1mV | |
| Phase erro | ≤0.5° | |
| Linearity | ±0.2% of reading | |
| Bandwidth | 1Hz to 100kHz(-3dB) | |
| Operating temperature | -30 °C to 80 °C | |
| Storage temperature | -40 °C to 90°C | |
ข้อมูลเพิ่มเติม
| น้ำหนัก | 0.4 กก. |
|---|---|
| ขนาด | 15 × 10 × 5 เซนติเมตร |
